Design Detailing – Weather Rite – HVAC
- Nearly 2200 parts, 400 weldments & 350 assemblies were converted from AutoCAD to Solid Works
- Standardization rules were set for part creation so that part orientation will match assembly orientation
- Weldment & assemblies were restructured as per PDF bill of material. Bill of material on Solid Works drawings are now matching PDF & not input AutoCAD drawings.
